MS300系列
| 標準機種IP20 / IP40 標準機種 (0~599 Hz) | 標準機種IP20 / IP40 標準機種 (0~599 Hz) | |||||||||||||
| 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | |||||
| 適用電機功率 | 輸出電流[A] | 適用電機功率 | 輸出電流 | |||||||||||
| [HP] | [kw] | [HP] | [kw] | [A] | ||||||||||
| 115V單相 | 460V三相 | |||||||||||||
| VFD1A6MS11ANSAA | 0.25 | 0.2 | 1.6 | A | — | VFD1A5MS43ANSAA | 0.5 | 0.4 | 1.5 | A | ||||
| VFD1A6MS11ENSAA | √ | VFD1A5MS43ENSAA | √ | |||||||||||
| VFD2A5MS11ANSAA | 0.5 | 0.4 | 2.5 | VFD1A5MS43AFSAA | B | √ | ||||||||
| VFD2A5MS11ENSAA | √ | VFD2A7MS43ANSAA | 1 | 0.75 | 2.7 | A | ||||||||
| VFD4A8MS11ANSAA | 1 | 0.75 | 4.8 | C | VFD2A7MS43ENSAA | √ | ||||||||
| VFD4A8MS11ENSAA | √ | VFD2A7MS43AFSAA | B | √ | ||||||||||
| 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | WFDAA2MS43ANSAA | 2 | 1.5 | 4.2 | B | |||||
| 適用電機功率 | 輸出電流[A] | VFD4A2MS43ENSAA | √ | |||||||||||
| [HP] | [kw] | VFD4A2MS43AFSAA | √ | |||||||||||
| 230V單相 | VFD5A5MS43ANSAA | 3 | 2.2 | 5.5 | C | |||||||||
| VFD1A6MS21ANSAA | 1/4 | 0.2 | 1.6 | A | VFD5A5MS43ENSAA | √ | ||||||||
| VFD1A6MS21ENSAA | √ | VFD5A5MS43AFSAA | √ | |||||||||||
| VFD1A6MS21AFSAA | B | √ | VFD9AOMS43ANSAA | 5 | 3.7/4 | 9 | C | |||||||
| VFD2A8MS21ANSAA | 0.5 | 0.4 | 2.8 | A | VFD9AOMS43ENSAP | √ | ||||||||
| VFD2A8MS21ENSAA | √ | VFD9A0MS43AFSAA | √ | |||||||||||
| VFD2A8MS21AFSAA | B | √ | VFD13AMS43ANSAA | 7.5 | 5.5 | 13 | D | |||||||
| VFD4A8MS21ANSAA | 1 | 0.75 | 4.8 | B | VFD13AMS43ENSAA | √ | ||||||||
| VFD4A8MS21AFSAA | √ | VFD13AMS43AFSAA | √ | |||||||||||
| VFD4A8MS21ENSAA | √ | VFD17AMS43ANSAA | 10 | 7.5 | 17 | D | ||||||||
| VFD7A5MS21ANSAA | 2 | 1.5 | 7.5 | C | VFD17AMS43ENSAA | √ | ||||||||
| VFD7A5MS21AFSAA | √ | VFD17AMS43AFSAA | √ | |||||||||||
| VFD7A5MS21ENSAA | √ | VFD25AMS43ANSAA | 15 | 11 | 25 | E | ||||||||
| VFD11AMS21ANSAA | 3 | 2.2 | 11 | C | VFD25AMS43ENSAA | √ | ||||||||
| VFD11AMS21AFSAA | √ | VFD25AMS43AFSAA | √ | |||||||||||
| VFD11AMS21ENSAA | √ | VFD32AMS43ANSAA | 20 | 15 | 32 | E | ||||||||
| 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | VFD32AMS43ENSAA | √ | ||||||||
| 適用電機功率 | 輸出電流[A] | VFD32AMS43AFSAA | √ | |||||||||||
| [HP] | [kw] | VFD3BAMS43ANSAA | 25 | 18.5 | 38 | F | ||||||||
| 230V三相 | VFD38AMS43ENSAA | √ | ||||||||||||
| VFD1A6MS23ANSAA | 0.25 | 0.2 | 1.6 | A | — | VFD38AMS43AFSAA | √ | |||||||
| VFD1A6MS23ENSAA | √ | VFD45AMS43ANSAA | 30 | 22 | 45 | F | ||||||||
| VFD2A8MS23ANSAA | 0.5 | 0.4 | 2.8 | VFD45AMS43ENSAA | √ | |||||||||
| VFD2A8MS23ENSAA | √ | VFD45AMS43AFSAA | √ | |||||||||||
| VFD4A8MS23ANSAA | 1 | 0.75 | 4.8 | 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | ||||||
| VFD4A8MS23ENSAA | √ | 適用電機功率 | 輸出電流 | |||||||||||
| VFD7A5MS23ANSAA | 2 | 1.5 | 7.5 | B | [HP] | [kw] | [A] | |||||||
| VFD7A5MS23ENSAA | √ | 575V三相 | ||||||||||||
| VFD11AMS23ANSAA | 3 | 2.2 | 11 | C | VFD1A7MS53ANSAA | 1 | 0.75 | 1.7 | A | — | — | |||
| VFD11AMS23ENSAA | √ | VFD3A0MS53ANSAA | 2 | 1.5 | 3 | B | ||||||||
| VFD17AMS23ANSAA | 5 | 3.7/4 | 17 | C | VFD4A2MS53ANSAA | 3 | 2.2 | 4.2 | C | |||||
| VFD17AMS23ENSAA | √ | VFD6A6MS53ANSAA | 5 | 3.7 | 6.6 | |||||||||
| VFD25AMS23ANSAA | 7.5 | 5.5 | 25 | D | VFD9A9MS53ANSAA | 7.5 | 5.5 | 9.9 | D | |||||
| VFD25AMS23ENSAA | √ | VFD12AMS53ANSAA | 10 | 7.5 | 12.2 | |||||||||
| VFD33AMS23ANSAA | 10 | 7.5 | 33 | E | ||||||||||
| VFD33AMS23ENSAA | √ | |||||||||||||
| VFD49AMS23ANSAA | 15 | 11 | 49 | |||||||||||
| VFD49AMS23ENSAA | √ | |||||||||||||
| VFD65AMS23ANSAA | 20 | 15 | 65 | F | ||||||||||
| VFD65AMS23ENSAA | √ | |||||||||||||
| 標準機種IP66 標準機種(0~599 Hz） | 標準機種IP20 / IP40 標準機種 (0~~1500 Hz) | ||||||||||||
| 型號 | 額定 | 框號 | 內置EMC 濾波器 | 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | |||||
| 適用電機功率 | 輸出電流 | 適用電機功率 | 輸出電流 | ||||||||||
| [HP] | [kw] | [A] | [HP] | [kw] | [A] | ||||||||
| 230 V 單相 | 230V 單相 | ||||||||||||
| VFD2A8MS21MNSAA | 1/2 | 0.4 | 2.8 | A | VFD7A5MS21ANSHA | 2 | 1.5 | 7.5 | C | ||||
| VFD2A8MS21MFSAA | √ | VFD7A5MS21ENSHA | √ | ||||||||||
| VFD4A8MS21MNSAA | 1 | 0.75 | 4.8 | VFD7A5MS21AFSHA | √ | ||||||||
| VFD4A8MS21MFSAA | √ | VFD11AMS21ANSHA | 3 | 2.2 | 11 | C | |||||||
| VFD7A5MS21MNSAA | 2 | 1.5 | 7.5 | VFD11AMS21ENSHA | √ | ||||||||
| VFD7A5MS21MFSAA | B | √ | VFD11AMS21AFSHA | √ | |||||||||
| VFD11AMS21MNSAA | 3 | 2.2 | 11 | 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | |||||
| VFD11AMS21MFSAA | √ | 適用電機功率 | 輸出電流 | ||||||||||
| 型號 | 額定 | 框號 | 內置EMC 濾波器 | [HP] | [kw] | [A] | |||||||
| 適用電機功率 | 輸出電流 | 230V 三相 | |||||||||||
| [HP] | [kw] | [A] | VFD7A5MS23ANSHA | 2 | 1.5 | 7.5 | B | — | |||||
| 230 V 三相 | VFD7A5MS23ENSHA | √ | |||||||||||
| VFD2A8MS23MNSAA | 1/2 | 0.4 | 2.8 | A | — | VFD11AMS23ANSHA | 3 | 2.2 | 11 | C | |||
| VFD4A8MS23MNSAA | 1 | 0.75 | 4.8 | VFD11AMS23ENSHA | √ | ||||||||
| VFD7A5MS23MNSAA | 2 | 1.5 | 7.5 | VFD17AMS23ANSHA | 5 | 3.7/4 | 17 | C | |||||
| VFD11AMS23MNSAA | 3 | 2.2 | 11 | B | VFD17AMS23ENSHA | √ | |||||||
| VFD17AMS23MNSAA | 5 | 3.7 | 17 | VFD25AMS23ANSHA | 7.5 | 5.5 | 25 | D | |||||
| VFD25AMS23MNSAA | 7.5 | 5.5 | 25 | C | VFD25AMS23ENSHA | √ | |||||||
| 型號 | 額定 | 框號 | 內置EMC 濾波器 | VFD33AMS23ANSHA | 10 | 7.5 | 33 | E | |||||
| 適用電機功率 | 輸出電流 | VFD33AMS23ENSHA | √ | ||||||||||
| [HP] | [kw] | [A] | VFD49AMS23ANSHA | 15 | 11 | 49 | E | ||||||
| 460 V 三相 | VFD49AMS23ENSHA | √ | |||||||||||
| VFD1A5MS43MNSAA | 1/2 | 0.4 | 1.5 | A | VFD65AMS23ANSHA | 20 | 15 | 65 | F | ||||
| VFD1A5MS43MFSAA | √ | VFD65AMS23ENSHA | √ | ||||||||||
| VFD2A7MS43MNSAA | 1 | 0.75 | 2.7 | 型號 | 額定 | 框號 | 內置EMC 濾波器 | IP40 機種 | |||||
| VFD2A7MS43MFSAA | √ | 適用電機功率 | 輸出電流 | ||||||||||
| VFD4A2MS43MNSAA | 3 | 1.5 | 4.2 | [HP] | [kw] | [A] | |||||||
| VFD4A2MS43MFSAA | √ | 460V 三相 | |||||||||||
| VFD5A5MS43MNSAA | 3 | 2.2 | 5.5 | VFD4A2MS43ANSHA | 2 | 1.5 | 4.2 | B | |||||
| VFD5A5MS43MFSAA | √ | VFD4A2MS43ENSHA | √ | ||||||||||
| VFD9AOMS43MNSAA | 5 | 3.7 | 9 | B | VFD4A2MS43AFSHA | √ | |||||||
| VFD9ADMS43MFSAA | √ | VFD5A5MS43ANSHA | 3 | 2.2 | 5.5 | C | |||||||
| VFD13AMS43MNSAA | 7.5 | 5.5 | 13 | C | VFD5A5MS43ENSHA | √ | |||||||
| VFD13AMS43MFSAA | √ | VFD5A5MS43AFSHA | √ | ||||||||||
| VFD17AMS43MNSAA | 10 | 7.5 | 17 | VFD9AOMS43ANSHA | 5 | 3.7/4 | 9 | C | |||||
| VFD17AMS43MFSAA | √ | VFD9AOMS43ENSHA | √ | ||||||||||
| VFD9AOMS43AFSHA | √ | ||||||||||||
| VFD13AMS43ANSHA | 7.5 | 5.5 | 13 | D | |||||||||
| VFD13AMS43ENSHA | √ | ||||||||||||
| VFD13AMS43AFSHA | √ | ||||||||||||
| VFD17AMS43ANSHA | 10 | 7.5 | 17 | D | |||||||||
| VFD17AMS43ENSHA | √ | ||||||||||||
| VFD17AMS43AFSHA | √ | ||||||||||||
| VFD25AMS43ANSHA | 15 | 11 | 25 | E | |||||||||
| VFD25AMS43ENSHA | √ | ||||||||||||
| VFD25AMS43AFSHA | √ | ||||||||||||
| VFD32AMS43ANSHA | 20 | 15 | 32 | E | |||||||||
| VFD32AMS43ENSHA | √ | ||||||||||||
| VFD32AMS43AFSHA | √ | ||||||||||||
| VFD38AMS43ANSHA | 25 | 18.5 | 38 | F | |||||||||
| VFD38AMS43ENSHA | √ | ||||||||||||
| VFD38AMS43AFSHA | √ | ||||||||||||
| VFD45AMS43ANSHA | 30 | 22 | 45 | F | |||||||||
| VFD45AMS43ENSHA | √ | ||||||||||||
| VFD45AMS43AFSHA | √ | ||||||||||||
應用領域
機床、紡織機、木工機械、包裝機、電子制造、風機、水泵、空壓機
技術規格
- 支持感應電機、永磁電機開回路控制
- 輸出頻率范圍 0 ~ 599Hz (標準機種)
- 頻 1,500Hz 輸出 (機種，僅支持感應電機 V/f 控制)
- 內置 PLC 可程序編輯 (2K steps)
- 內置 33kHz 脈沖輸入端子 x1 (MI7)
- 內置 33kHz 脈沖輸出端子 x1 (DFM)
- EMC 濾波器 (內置/選購)
- 具認證 Torque Off (SIL2/PLd)
- 全系列內置抱閘晶體
- 新電路板涂層 (IEC 60721-3-3 class 3C2)，強化環境耐受性
- 5 位數高亮度 LED keypad (可使用 E/M/B 延長線外拉至控制盤面板)
- 支持多種通訊接口：CANopen、DeviceNet、EtherCAT、EtherNet/IP、Profibus DP、Modbus TCP、PROFINET
